Application:Laser Engraving

Applicable Material:Acrylic, Glass, Leather, MDF, metal, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, wood

Engraving Area:400*430mm

Laser Type:DIODE

Engraving Speed:0-3,000MM/Min

Graphic Format Supported:NC, DXF, BMP, JPG, PNG, Other Static image.

Condition:New

Place of Origin:Guangdong, China

Brand Name:Ortur

Dimension(L*W*H):570*550*175mm

Certification:ce

Laser Source Brand:China famous brand

Weight (KG):3.5 KG

Key Selling Points:High Safety Level

Warranty:1 Year

After-sales Service Provided:Online support

Applicable Industries:Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Advertising Company

After Warranty Service:Video technical support, Online support, Spare parts

Local Service Location:None

Showroom Location:None

Machinery Test Report:Provided

Video outgoing-inspection:Provided

Marketing Type:New Product 2020

Warranty of core components:1 Year

Core Components:Mainboard, Laser module

Product name:engraver laser

Motherboard:OLM V1.3 Motherboard,with STM32 MCU

Protection:Active Position Protection

Key words:laser engraving machine laser cutter engraver

Function:Laser Beam Safety Guard

Pixel Accuracy:Adjustable (Default: 300 pixels per inch, about 0.81um Pixel Accuracy)

Available Laser Modules:LU1-2, LU1-3, LU1-4

Wave Length:445±5nm

G.W:3.5KG

Features

●Specialized Motherboard with STM32 MCU
●The Most Advanced 32Bits Laser Engraver Firmware
Ortur laser master firmware, smarter, faster, higher precision and easier to use.
● Laser power range could be S0 - S1000
● Engraving speed could be as high as 3000MM/Min.
●Active Position Protection
●Laser Beam Safety Guard
●Exposure Duration Detection and Limitation
● LaserGRBL ( free software ) supports Windows XP, 7, 8, 10.
● LightBurn (not free software, lightburnsoftware.com ) supports Windows, Mac OS, and Linux. It's the most popular paid carving software in the world, very easy to use.
● This laser engraver supports PWM mode.
● Pre-assembled parts, just need 10 - 20 minutes to install the machine.
● 400 x 430 mm large engraving area.
● Aluminum profile frame + structured cabling, solid structure, smooth operation, attractive appearance
● Synchronizing shaft mechanical structure, avoid out-sync on two Y rails, during full speed engraving.
